Motor Testing & Sensors Torque Sensors, Brakes & Clutches Dynamometers, Electronics & Fixtures, Custom Motor Test Systems & Solutions Data Acquisition & Testing Software www.magtrol.com MAGTROL INC. MAGTROL S.A. Magtrol, Inc. located in Buffalo, New York, USA, is the company’s headquarters as well as a manufacturing facility. Founded in 1953 by John E. Duncan, a pioneer in magnetic hysteresis phenomena, the company quickly gained recognition in the field of measurement technology. Magtrol S.A. is located in Rossens, Switzerland. Founded in 1952, the company evolved from the Instrumentation Division of Vibro-Meter (today Meggitt S.A.). Since then, Magtrol Inc. has continued to innovate and become a world-class leader in Motor Testing Solutions, Hysteresis Brakes & Clutches. In 2000, Magtrol Inc. acquired this division and founded Magtrol S.A. The aquisition was a valuable addition to the company adding its expertise in torque measurement (essential for Motor Testing), Dynamometers, Custom Motor Test Systems, and also Load-Force-Weight measurement solutions and Displacement measurement. LOAD-FORCE-WEIGHT SOLUTIONS CUSTOM MOTOR TEST SYSTEMS DISPLACEMENT TRANSDUCERS Magtrol designs complete measurement systems from transducers to conditioning electronics. These solutions provide high-precision static and dynamic measurement and can be used in various fields, including: micro-measurement (medical, watchmaking), heavy industrial equipment for overload detection and control (hoists, cranes, winches, ski lifts,...), civil engineering (anchors), etc. Our solutions can be adapted to any type of environment including extreme conditions, such as tropical, offshore, harbor,... Magtrol has distinguished itself in its ability to design and implement innovative motor test systems. With more than 70 years of experience, the company offers fully customized test bench systems. These can be configured to be used in a laboratory, certification, production or quality control. Magtrol offers widely recognized expertise to meet a multitude of requirements, whether it's for series testing, extreme specifications or special climatic environments. Magtrol has specialized in non-contact displacement transducer technology. With their rugged construction, insensitivity to shock and long life, these transducers allow high-precision measurements in extreme environments (temperature, pressure, abrasive,...). Jointly developed for the hydraulic industry, these sensors are used in hydraulic cylinders, control valves, steam inlet valves, stone crushers, boat engines and propellers,... 2 www.magtrol.com Magtrol Group William A. III MULROY President Tom RYMARCZYK CEO Magtrol, Inc. For more than 70 years, Magtrol Group has been developing and producing high-tech transducers and systems for a wide range of applications, including testing and certification of electric motors, torque measurement (motors, pumps, drives, gearboxes, etc.), force and load measurement (cranes, hoists, mechanical lifts, civil engineering anchors, etc.) and displacement measurement in control systems. The company serves a variety of fields including but not limited to household appliances, automotive, aeronautics, test or research laboratories, medical, power generation, harbor cranes, transportation, civil engineering. Since its founding, customer service has been a priority at Magtrol. The company utilizes our expertise to offer specific solutions ranging from custom sensors to customized turnkey systems. Our innovative R&D department regularly expands our offerings by developing new products and creative solutions. Our products are exported to most countries throughout the word providing a worldwide presence and reputation widely recognized by all professionals in the field. Despite our international activity, Magtrol Group reinforces the foundation of our success through the involvement of our employees and the support of the local economic environment. Magtrol is committed to being involved in the local economy through collaborations with research and training organizations. Our core values allow the company to benefit from hard-working, experienced and dedicated employees who contribute to the continued success of Magtrol. TABLE OF CONTENT Jocelyn CATTIN CEO Magtrol SA www.magtrol.com Torque Sensors 4 In-Line Torque Sensors 6 Torque Flange Sensors 8 Reaction Torque Sensors 9 Cogging Torque System 10 Display, Electronics & Software 11 Customize your own Torque System ! 13 Torque Calibration Laboratory 14 Industrial Brakes 16 Power Supplies 23 Dynamometers 24 Hysteresis Brake Dynamometers 26 Eddy-Current Dynamometers 28 Powder Dynamometers & TANDEM 30 Mega Speed Dynamometer 32 4Q Dynamometers 33 Electronics & Software 34 System Options & Accessories 38 Couplings 40 Modular Motor Test Systems 42 Custom Motor Test Benches & Systems 44 Services, Consulting & Support 46 3
