EDMOLIF T PRODUCT CATALOGUE SMART LIFTING SOLUTIONS A WORLD CLASS GLOBAL PARTNER CONTENT u EDMOLIFT AB 10 12 14 16 18 20 22 24 Welcome to our world Smart Lifting Solutions Good ergonomics Innovation is our watchword Environmental investment Lifting solutions for every need Service & support A journey through time with EdmoLift u EDMOLIFT GUIDE 28 29 30 31 What is a lift table Benefits with lift tables Lift table models Checklist for effective handling of materials How to choose the right lift table Pit drawing and surface treatment Safety regulations Work positioners and more lifting solutions 32 33 34 38 u PRODUCTS 43 44 46 47 Single Scissors Heavy Duty lift tables Horizontal Double Scissor Vertical Double, Triple and Quattro Scissor Lorry Loaders Low Profile Lift Tables LTT 750 Armlifts Tilt tables for table and floor mounting Pallet lifter Lift table accessories PL 2002 - Pallet positioner Pallet Buddy - Pallet magazine Lift trolleys Work Positioners Lifting solutions in stainless steel Movexx Electric Tuggers Goods lift Car lift tables Terms of delivery 48 56 57 58 60 61 62 68 69 72 73 81 84 86 90 92 02 ERGONOMICS WITH LIFT AND TILT When Volvo Personvagnar in Olofström built a new and revolutionary pressure hardening line for sheet metal components for the Volvo XC90, EdmoLift were tasked with customising Armlifts for material handling at the 3d laser cutting system. There are four Armlifts at each laser cutting station and EdmoLift has delivered 48 Armlifts in all to the factory. The ALT 3000 Armlifts have been substantially enlarged to be able to handle the large panels that are processed. The panels are used in the ”safety cage” on the XC90 and are high strength so that they do not deform in a crash. In order to achieve the best ergonomic results the Armlifts combine lift and tilt in the same unit and also have a low height so that the operators need never to bend or stretch to pick up the material. The Armlifts are also installed in pits and can be lowered completely down to floor level when not in use. This provides a free floor surface. 03
